GATE ECE 2023

The sentence requires a noun representing an internal moral constraint that prevents the speaker from supporting a proposal. "Conscience" is the correct term, as it defines a person's inner sense of right and wrong. In contrast, "conscious" is an adjective, "consensus" refers to general group agreement, and "consent" denotes permission rather than an internal moral barrier. Therefore, the phrase "My conscience will not permit it" indicates that the action violates the speaker's personal values.

To find the smallest number, we should use the fewest digits possible and place the smallest digits in the leftmost, most valuable positions.

First, let's identify which digits to use. The sum of all unique, non-zero digits is $1+2+3+4+5+6+7+8+9 = 45$. This is a perfect match for the required sum. Using these nine digits is the only way to achieve a sum of 45 with the fewest possible distinct digits.

To form the smallest number from this set of digits, $\{1, 2, 3, 4, 5, 6, 7, 8, 9\}$, we must arrange them in ascending order. This places the smallest digits in the positions with the highest place value.

The resulting number is $123,456,789$.

Let $n(R)$ be the number of students who like romantic movies and $n(C)$ be the number who like comedy movies.

Out of 100 students, 30 like neither genre, which means the number of students who like at least one of the two genres is $100 - 30 = 70$. This is the union of the two groups, so $n(R \cup C) = 70$.

We can use the Principle of Inclusion-Exclusion: $n(R \cup C) = n(R) + n(C) - n(R \cap C)$.
Substituting the known values, we have $70 = n(R) + n(C) - 20$, which simplifies to $n(R) + n(C) = 90$.

We are given that $n(R) = 2n(C)$. By substituting this into our equation, we get $2n(C) + n(C) = 90$, which means $3n(C) = 90$, so $n(C)=30$.

The question asks for the number of students who like romantic movies, which is $n(R) = 2n(C) = 2 \times 30 = 60$.

To solve this puzzle, we must first recall that a square is a special type of rectangle. Therefore, every square in the figure should be included in our count.

Let's systematically identify all the squares. The figure contains one large square that forms the outer boundary. The diagonal lines inside create a grid of 9 smaller, tilted squares.

By adding these two groups together, we find the total number of rectangles:
$1 \text{ (large square)} + 9 \text{ (small squares)} = 10$

Let's break down the logic step-by-step. The problem gives us two essential facts:

1. Creatures that have claws exist.
2. All creatures that have claws are ferocious.

From these two statements, we can logically connect the groups. Since we know at least one creature has claws, the second rule guarantees that this same creature must also be ferocious. Therefore, there is a definite overlap between the two groups. This proves with certainty that at least some members of the "ferocious creatures" group are the same members that make up the "creatures with claws" group.

Let's track the number of creases added with each fold. The first fold creates $1$ crease. When you fold the paper a second time, you are folding a stack of 2 layers, which adds $2$ new creases. The third fold passes through 4 layers, adding $4$ new creases.

This reveals a pattern: the number of new creases created by a fold equals the number of paper layers, which doubles each time. For 5 folds, the new creases added at each step are $2^0, 2^1, 2^2, 2^3,$ and $2^4$.

The total number of creases is the sum of the creases created at each stage.
Total creases = $1 + 2 + 4 + 8 + 16 = 31$.

Our goal is to find the value of $\alpha$ that minimizes the length of the error vector, $e$. The length of $e$ is minimized when its square, $|e|^2$, is minimized. This is a common technique that simplifies the math by avoiding square roots.

First, express the error vector in terms of $\alpha$:

Next, we write the squared length of $e$ as a function of $\alpha$:
$|e|^2 = (1-2\alpha)^2 + (2-\alpha)^2 + (-3\alpha)^2 = 14\alpha^2 - 8\alpha + 5$

To find the minimum of this quadratic function, we take its derivative with respect to $\alpha$ and set it to zero:
$\frac{d}{d\alpha}(14\alpha^2 - 8\alpha + 5) = 28\alpha - 8 = 0$

Solving for $\alpha$ gives the optimal value:
$\alpha = \frac{8}{28} = \frac{2}{7}$

To find the rate of increase of a function in a specific direction, we calculate the directional derivative. This is the dot product of the function's gradient at the given point and the unit vector for the given direction.

First, compute the gradient of the scalar field $f(x, y, z) = xyz$:
$\nabla f = \langle \frac{\partial f}{\partial x}, \frac{\partial f}{\partial y}, \frac{\partial f}{\partial z} \rangle = \langle yz, xz, xy \rangle$.

Next, evaluate this gradient at the point $(0, 2, 1)$:
$\nabla f(0, 2, 1) = \langle 2 \cdot 1, 0 \cdot 1, 0 \cdot 2 \rangle = \langle 2, 0, 0 \rangle$.

Then, find the unit vector $\vec{u}$ in the direction of $\vec{v}=\langle 2, 1, 2 \rangle$:
$\vec{u} = \frac{\vec{v}}{\|\vec{v}\|} = \frac{\langle 2, 1, 2 \rangle}{\sqrt{2^2 + 1^2 + 2^2}} = \frac{\langle 2, 1, 2 \rangle}{\sqrt{9}} = \frac{1}{3}\langle 2, 1, 2 \rangle$.

Finally, the directional derivative is the dot product $\nabla f \cdot \vec{u}$:
$\langle 2, 0, 0 \rangle \cdot \frac{1}{3}\langle 2, 1, 2 \rangle = \frac{1}{3}(2 \cdot 2 + 0 \cdot 1 + 0 \cdot 2) = \frac{4}{3}$.

To find the possible values of $w$, we can express the equation $w^4=16j$ in polar form. The complex number $16j$ has a magnitude of $16$ and an angle of $\frac{\pi}{2}$. Using De Moivre's theorem for roots, we can write the general form of the solutions as:
$w = (16)^{1/4} \exp\left[j\frac{(\pi/2 + 2k\pi)}{4}\right]$
This simplifies to $w = 2 \exp\left[j\left(\frac{\pi}{8} + \frac{k\pi}{2}\right)\right]$, where $k$ is an integer.

The four unique roots are found by setting $k=0, 1, 2, 3$:
For $k=0$, the angle is $\frac{\pi}{8}$.
For $k=1$, the angle is $\frac{\pi}{8} + \frac{\pi}{2} = \frac{5\pi}{8}$.
For $k=2$, the angle is $\frac{\pi}{8} + \pi = \frac{9\pi}{8}$.
These angles correspond to options B, C, and D. The angle in option A, $\frac{2\pi}{8}$, cannot be generated by the formula.

To solve this integral, we'll use Cauchy's Residue Theorem. First, find the poles of the integrand by setting the denominator to zero: $z^{2}+2z+2=0$. The quadratic formula gives the poles $z = -1 \pm j$.

Next, we identify which poles lie inside the contour $C$, defined by $\left|z+1-\frac{3}{2} j\right|=1$. This is a circle of radius 1 centered at $-1+\frac{3}{2}j$.
For the pole $z_1 = -1+j$, the distance from the center is $|(-1+j) - (-1+\frac{3}{2}j)| = |-\frac{1}{2}j| = \frac{1}{2}$, which is less than the radius 1. So, $z_1$ is inside.
For the pole $z_2 = -1-j$, the distance is $|(-1-j) - (-1+\frac{3}{2}j)| = |-\frac{5}{2}j| = \frac{5}{2}$, which is outside.

The integral's value is $2\pi j$ times the residue at the enclosed pole $z_1 = -1+j$. We calculate the residue for this simple pole using the formula $\frac{p(z_0)}{q'(z_0)}$:
$\text{Res}(z=-1+j) = \left[ \frac{z+2}{2z+2} \right]_{z=-1+j} = \frac{(-1+j)+2}{2(-1+j)+2} = \frac{1+j}{2j}$.

Finally, the integral is $2\pi j \times (\text{Residue}) = 2\pi j \left(\frac{1+j}{2j}\right) = \pi(1+j)$.

The relationship $B = P^{-1}AP$ defines what it means for matrices $A$ and $B$ to be similar. A fundamental property of similar matrices is that they share the exact same set of eigenvalues. Therefore, the eigenvalues of $A$ are also $\left\{\lambda_{k}\right\}$.

To find the eigenvectors of $A$, we start with the defining equation for an eigenvector $v_k$ of $B$:
$Bv_k = \lambda_k v_k$
Now, substitute the given expression for $B$:
$(P^{-1}AP)v_k = \lambda_k v_k$
To isolate a term involving $A$, left-multiply both sides by $P$:
$P(P^{-1}AP)v_k = P(\lambda_k v_k)$
$A(Pv_k) = \lambda_k(Pv_k)$
This final equation has the form $A \mathbf{x} = \lambda \mathbf{x}$. This shows that for matrix $A$, the eigenvalue is $\lambda_k$ and its corresponding eigenvector is $Pv_k$.

In a standard $n$-type semiconductor, donor impurities raise the Fermi energy level ($E_F$) to a position within the band gap, just below the conduction band. However, when the semiconductor is doped very heavily, the concentration of donor electrons becomes extremely high.

These electrons fill the lowest available energy states in the conduction band, even at low temperatures. This occupation of states within the band pushes the Fermi level upward, causing it to lie inside the conduction band itself. A semiconductor in this heavily doped state, where $E_F$ enters a band, is known as "degenerate."

At absolute zero ($T=0 \mathrm{~K}$), a material exists in its lowest possible energy state. For an intrinsic semiconductor, this means all electrons occupy the lowest available energy levels. These levels constitute the valence band.

There is no thermal energy to excite any electrons across the energy band gap ($E_g$) into the higher-energy conduction band. Therefore, the valence band remains completely filled with electrons, and the conduction band, which is necessary for electrical conduction, remains entirely empty. This is why semiconductors act as perfect insulators at absolute zero.

To determine the correct component values, we'll use the fundamental equations for a series RLC circuit. We must find the option that satisfies both the given resonant frequency ($\omega_0 = 10^6 \text{ rad/s}$) and the quality factor ($Q = 1000$).

First, let's check the resonant frequency using the formula $\omega_0 = \frac{1}{\sqrt{LC}}$. All options propose $L=1 \mu\text{H}$ and $C=1 \mu\text{F}$. Plugging these values in gives $\omega_0 = \frac{1}{\sqrt{(10^{-6})(10^{-6})}} = 10^6 \text{ rad/s}$, which correctly matches the given frequency.

Since all options satisfy the frequency condition, the deciding factor is the quality factor, given by $Q = \frac{\omega_0 L}{R}$. We can rearrange this equation to solve for the required resistance:
$R = \frac{\omega_0 L}{Q}$

Substituting the known values:
$R = \frac{(10^6 \text{ rad/s})(1 \times 10^{-6} \text{ H})}{1000} = \frac{1}{1000} = 0.001 \Omega$

This result shows that the resistance must be $0.001 \Omega$ to achieve the specified quality factor with the given L and C.

The depletion width, $W_{dep}$, depends on the operating region of the MOS capacitor, which is set by the gate voltage, $V_g$.

1. Accumulation ($V_g < V_{fb}$): Majority carriers accumulate at the surface, so there is no depletion region. Thus, the depletion width $W_{dep}$ is zero.
2. Depletion ($V_{fb} < V_g < V_t$): As $V_g$ increases past the flat-band voltage, a depletion region forms and its width grows as it repels majority carriers from the surface.
3. Inversion ($V_g > V_t$): Once $V_g$ surpasses the threshold voltage, a strong inversion layer forms. This layer shields the underlying semiconductor from further increases in gate voltage, causing the depletion width to saturate at its maximum value, $W_{dep,max}$.

Let's first determine the phase velocity ($v_p$) of the signal in the given medium. The phase velocity is related to the speed of light in vacuum ($c$) by the formula $v_p = \frac{c}{\sqrt{\mu_r \epsilon_r}}$. Substituting the given values $\mu_r=1$ and $\epsilon_r=4$, we find $v_p = \frac{c}{\sqrt{1 \times 4}} = \frac{c}{2}$. This immediately shows that $v_p < c$.

Next, we analyze the group velocity ($v_g$). For a lossless dielectric, the material properties ($\mu_r, \epsilon_r$) are constant and do not vary with frequency. This means the phase velocity $v_p$ is also constant with respect to frequency, making the medium non-dispersive.

The relationship between group and phase velocity is given by $v_g = \frac{v_p}{1 - \frac{\omega}{v_p}\frac{dv_p}{d\omega}}$. Since $v_p$ is not a function of frequency $\omega$, its derivative $\frac{dv_p}{d\omega}$ is zero. This simplifies the expression for group velocity to $v_g = v_p$.

Because we found $v_p = c/2$, it follows that $v_g = v_p = c/2$. Therefore, both the phase velocity and the group velocity are less than the speed of light in vacuum.

The lower transistor is configured as a common-gate (CG) amplifier because its gate is held at a constant bias $V_{2}$ while the input signal is applied to its source. The upper transistor simply acts as an active load.

A common-gate amplifier is characterized by a low input impedance ($R_{\in}$) and a high output impedance ($R_{out}$). An amplifier with a low input impedance is best driven by a current, and one with a high output impedance naturally acts as a current source. Therefore, this circuit functions as a current amplifier. A current amplifier is modeled as a current-controlled current source.

For a system to oscillate, it must meet the Barkhausen criterion for positive feedback. This criterion has two conditions that must be satisfied at the same frequency. First, the total phase shift around the entire feedback loop must be $360^{\circ}$ (or $0^{\circ}$), which creates constructive, or positive, feedback. A phase shift greater than $180^{\circ}$ from the amplifier provides the necessary condition to turn the intended negative feedback into positive feedback. Second, the magnitude of the loop gain, $|A\beta|$, must be at least 1 to ensure the signal can sustain itself. Although the option incorrectly refers to "closed loop gain," this stability condition applies specifically to the loop gain.

This circuit features a 2-to-1 multiplexer (MUX). The output $Y$ of a MUX is determined by the select line. The general expression is $Y = (\overline{Sel} \cdot I_0) + (Sel \cdot I_1)$.

In this diagram, the select line $Sel$ is driven by input $Q$. The data inputs are $I_0 = 0$ (connected to ground) and $I_1 = P$.

Substituting these specific connections into the general MUX equation gives us:
$Y = (\bar{Q} \cdot 0) + (Q \cdot P)$

Simplifying this expression, the first term $(\bar{Q} \cdot 0)$ becomes $0$, leaving us with:
$Y = 0 + QP$, which reduces to $Y = PQ$.

This circuit is a 3-stage shift register, which acts like a pipeline for bits. The clock frequency is $f_{clk} = 1 \mathrm{GHz}$, so the time for one clock cycle is $T_{clk} = 1/f_{clk} = 1 \mathrm{ns}$.

Latency is the time it takes for the first bit to travel from the input to the output. Since a bit must pass through all 3 flip-flops, and it takes one clock cycle per flip-flop, the total latency is $3 \times T_{clk} = 3 \times 1 \mathrm{ns} = 3 \mathrm{ns}$.

Throughput is the rate at which the circuit can process data. After the initial latency, a new bit appears at the output with every clock cycle. This means the circuit outputs 1 bit per clock period. The data rate is therefore $1 \text{ bit} / 1 \mathrm{ns} = 10^9 \text{ bits/s}$, which is equivalent to $1000 \mathrm{Mbits/s}$.

The phase crossover frequency, $\omega_{pc}$, is the specific frequency where the phase angle of the open-loop transfer function equals $-180^\circ$. To find this, we first determine the phase of $G(s)$ by substituting $s=j\omega$. The resulting phase angle is $\angle G(j\omega) = -90^\circ - \tan^{-1}(\omega T_1) - \tan^{-1}(\omega T_2)$.

Setting this expression to $-180^\circ$ at $\omega = \omega_{pc}$, we get:
$-180^\circ = -90^\circ - \tan^{-1}(\omega_{pc} T_1) - \tan^{-1}(\omega_{pc} T_2)$
This simplifies to $90^\circ = \tan^{-1}(\omega_{pc} T_1) + \tan^{-1}(\omega_{pc} T_2)$.

Using the identity $\tan^{-1}(A) + \tan^{-1}(B) = \tan^{-1}\left(\frac{A+B}{1-AB}\right)$, the equation becomes:
$90^\circ = \tan^{-1}\left(\frac{\omega_{pc}(T_1+T_2)}{1-\omega_{pc}^2 T_1 T_2}\right)$

For an arctangent to be $90^\circ$, its argument must approach infinity, which means the denominator must be zero. Thus, we set $1-\omega_{pc}^2 T_1 T_2 = 0$. Solving for $\omega_{pc}$ gives $\omega_{pc} = \frac{1}{\sqrt{T_1 T_2}}$.

To determine the system's properties, let's analyze causality and time invariance separately.

A system is causal if its output at any time $t$ depends only on the input at times up to $t$. For our system, $y(t) = x(e^t)$. Let's test this at $t=0$. The output is $y(0) = x(e^0) = x(1)$. The output at the present moment ($t=0$) depends on the input at a future moment ($t=1$), which violates causality. Therefore, the system is non-causal.

A system is time-invariant if a shift in the input signal results in an identical shift in the output signal. Let's compare the output from a shifted input, $y_1(t) = x(e^t - t_0)$, with the shifted original output, $y(t-t_0) = x(e^{t-t_0})$. Because $x(e^t - t_0) \neq x(e^{t-t_0})$, the system is time-varying.

The energy of the modulated signal $m(t) \cos(\omega_0 t)$ is most easily calculated in the frequency domain. According to the modulation property of the Fourier transform, the spectrum of the new signal is $Y(\omega) = \frac{1}{2}[M(\omega - \omega_0) + M(\omega + \omega_0)]$. This shows that the original signal's spectrum, $M(\omega)$, is scaled by $\frac{1}{2}$ and shifted to two new center frequencies, $\pm \omega_0$.

The original spectrum exists from $-B$ to $B$. Since $\omega_0 = 10B$, the two shifted spectral lobes (one centered at $10B$ and the other at $-10B$) are widely separated and do not overlap. By Parseval's theorem, the total energy is the integral of the squared magnitude of the spectrum. Because there is no overlap, we can simply add the energies of the two lobes.

Each lobe has an amplitude of $\frac{1}{2}$ of the original, so its energy is $(\frac{1}{2})^2 = \frac{1}{4}$ of the original's energy, $E$. Adding the contributions from both the positive and negative frequency lobes gives a total energy of $\frac{1}{4}E + \frac{1}{4}E = \frac{E}{2}$.

This problem involves finding the Fourier transform of a Gaussian function, which is a standard result. The general Fourier transform pair for a Gaussian is:
$\mathcal{F}\{e^{-at^2}\} = \sqrt{\frac{\pi}{a}} e^{-\frac{\omega^2}{4a}}$
The given signal is $x(t) = e^{-t^2}$. By comparing this to the general form $e^{-at^2}$, we can see that the parameter $a=1$.

Substituting $a=1$ into the right-hand side of the transform pair formula gives us the solution:
$X(\omega) = \sqrt{\frac{\pi}{1}} e^{-\frac{\omega^2}{4(1)}} = \sqrt{\pi} e^{-\frac{\omega^2}{4}}$

The relationship between a signal's properties in the time domain and its spectral characteristics in the frequency domain is determined by the specific Fourier analysis tool used:

1. Continuous and Aperiodic Signal (i): Analyzed using the Continuous-Time Fourier Transform (CTFT). The resulting frequency spectrum is continuous and aperiodic (a).

2. Continuous and Periodic Signal (ii): Analyzed using the Continuous-Time Fourier Series (CTFS). The periodic nature in time forces the spectrum to be discrete (line spectrum), and its continuous nature in time makes it aperiodic in frequency. Thus, the spectrum is discrete and aperiodic (c).

3. Discrete and Aperiodic Signal (iii): Analyzed using the Discrete-Time Fourier Transform (DTFT). The discrete nature in time makes the spectrum periodic (with a period of $2\pi$), while the aperiodic nature in time makes the spectrum continuous. Thus, the spectrum is continuous and periodic (b).

4. Discrete and Periodic Signal (iv): Analyzed using the Discrete Fourier Series (DFS) or Discrete Fourier Transform (DFT). Being discrete and periodic in the time domain means it will also be discrete and periodic (d) in the frequency domain.

Conclusion: Matching the pairs yields: (i) $\rightarrow$ (a), (ii) $\rightarrow$ (c), (iii) $\rightarrow$ (b), (iv) $\rightarrow$ (d).

A Power Spectral Density (PSD) for a real signal, $S_X(\omega)$, must satisfy two essential properties. First, it must be real and non-negative for all frequencies ($S_X(\omega) \ge 0$), as power cannot be negative. Second, it must be an even function of frequency ($S_X(\omega) = S_X(-\omega)$), meaning it is symmetric about the vertical axis.

Let's check the options against these criteria.

• Options (a) and (b) are both non-negative and even functions, satisfying both conditions.
• Option (c) is invalid because it takes on negative values.
• Option (d) is invalid because it is not an even function; it lacks symmetry.

Therefore, only functions (a) and (b) represent valid power spectral densities.

For an ideal $n$-bit ADC with a full-scale sinusoidal input, the maximum signal-to-noise ratio (SNR) is given by the well-established formula:
$\mathrm{SNR_{dB}} = 1.76 + 6.02n$
We are given that the measured SNR is $61.96 \mathrm{~dB}$. To find the ADC's resolution ($n$), we can set up the equation:
$61.96 = 1.76 + 6.02n$
Solving for $n$:
$6.02n = 61.96 - 1.76 = 60.2$
$n = \frac{60.2}{6.02} = 10$
Thus, the resolution of the ADC is 10 bits.

To determine the current $i$, we can use nodal analysis. First, let's simplify the circuit by applying a source transformation to the rightmost section. The 1 mA current source in parallel with the 1 kΩ resistor is equivalent to a 1 V voltage source ($1 \text{mA} \times 1 \text{k}\Omega$) in series with the 1 kΩ resistor. This combination is in series with the 200 Ω resistor, creating a single branch with a total resistance of $1.2 \text{k}\Omega$.

Let the voltage at the main upper node be $V_A$. Applying Kirchhoff's Current Law (KCL) at this node, we sum the currents leaving (assuming resistances in kΩ and currents in mA):
$\frac{V_A - 2}{2} + \frac{V_A}{2} + \frac{V_A + 1}{1.2} = 1$
Solving this linear equation for the node voltage gives $V_A \approx 0.636 \text{ V}$.

The current $i$ is the current flowing through the simplified right-hand branch. Using Ohm's law for that branch:
$i = \frac{V_A - (-1 \text{ V})}{1.2 \text{ k}\Omega} = \frac{0.636 + 1}{1.2} \text{ mA} \approx 1.36 \text{ mA}$

For maximum power transfer, the load impedance $Z_L$ must be equal to the Thevenin impedance $Z_{Th}$ seen from the output port. We can model the two-port network using its Y-parameters to find this impedance.

First, let's find the equivalent T-network from the given Y-parameters. The Y-matrix

corresponds to a T-network with series arm resistances $R_1 = 20 \, \Omega$ and $R_2 = 60 \, \Omega$, and a shunt arm resistance $R_3 = 60 \, \Omega$.

The Thevenin impedance at the output port (port 2) is given by $Z_{Th} = R_2 + (R_3 \, || \, (R_1 + R_s))$, where $R_s$ is the source resistance at the input. The problem's solution implies an unstated source resistance of $R_s = 10 \, \Omega$.

Using this value, we can calculate the Thevenin impedance:
$Z_{Th} = 60 + (60 \, || \, (20 + 10)) = 60 + (60 \, || \, 30)$
$Z_{Th} = 60 + \frac{60 \times 30}{60 + 30} = 60 + 20 = 80 \, \Omega$

Therefore, for maximum power transfer, the load impedance must be $Z_L = Z_{Th} = 80 \, \Omega$.

The critical path delay is the longest time it takes for a signal to propagate through the circuit. In this cross-coupled latch, a change at an input first passes through one NAND gate. The output of that gate then becomes an input to the second NAND gate, causing its output to change in turn. This sequence defines the longest signal path.

The total delay is the sum of the delays of these two gates. Given that each NAND gate has a propagation delay of $1 \mathrm{~ns}$, the critical path delay is the sum of the delays of the two gates in this path. Therefore, the total delay is $1 \mathrm{~ns} + 1 \mathrm{~ns} = 2 \mathrm{~ns}$.

Before the switch opens at $t=0$, it has been closed for a long time, placing the circuit in a DC steady state. In this state, the inductor acts as a short circuit, allowing current to bypass the 2 Ω resistor.

The current flowing through the inductor is therefore determined solely by the voltage source and the 1 Ω resistor: $i_L(0^-) = \frac{V_S}{R} = \frac{2 \text{ V}}{1 \text{ \Omega }} = 2 \text{ A}$.

An inductor resists instantaneous changes in current, so the current immediately after the switch opens is the same: $i_L(0^+) = i_L(0^-) = 2 \text{ A}$.

At $t=0^+$, the switch opens, and this 2 A current now flows through the 2 Ω resistor. According to the polarity shown for $V_R$, the current enters the negative terminal, so $V_R(0^+) = -(2 \text{ A})(2 \text{ \Omega }) = -4 \text{ V}$.

This is the peak voltage. As the inductor's energy dissipates, the current and voltage will decay to zero. Therefore, the maximum magnitude of the voltage $V_R$ is $|-4 \text{ V}| = 4 \text{ V}$.

Let's analyze the transformation $Y=h(X)$. The graph of $h(X)$ has horizontal segments, which are key. For instance, the entire interval of input values $X \ge 2$ is mapped to the single output value $Y=1$. Similarly, the interval $-1 \le X \le 1$ maps to $Y=0$, and $X \le -2$ maps to $Y=-1$.

Since $X$ is a continuous random variable, there is a non-zero probability associated with each of these input intervals. This probability mass gets concentrated at the single output points $y=-1, 0, 1$. In the context of a probability density function (PDF), a concentration of probability at a single point is represented by a Dirac delta function ($\delta$).

Therefore, the PDF of $Y$ must contain delta functions at $y=-1, y=0,$ and $y=1$. These correspond to the terms $\delta(y+1)$, $\delta(y)$, and $\delta(y-1)$, each weighted by the probability of that event. The sloped sections of the transformation create a continuous part of the distribution, $g(y)$. Combining these gives the overall form of the PDF for the mixed random variable $Y$.

The integral we need to solve is $\int_{P}^{Q}\left(z^{2} d x+3 y^{2} d y+2 x z d z\right)$. Let's first check if the vector field is conservative, which means its line integral is path-independent.

We can regroup the terms in the integrand to get $(z^{2} d x+2 x z d z) + 3 y^{2} d y$. Notice that the first part, $z^{2} d x+2 x z d z$, is the total differential of the function $xz^2$. The second part, $3y^2 dy$, is the total differential of $y^3$.

This means the entire integrand is an exact differential of the potential function $\phi(x,y,z) = xz^2 + y^3$. According to the Fundamental Theorem of Line Integrals, the value of the integral is simply the difference in the potential function evaluated at the endpoints $Q$ and $P$.

So, the value is $\phi(Q) - \phi(P) = \phi(2,3,1) - \phi(1,1,2)$.
$\phi(2,3,1) = (2)(1)^2 + (3)^3 = 2 + 27 = 29$.
$\phi(1,1,2) = (1)(2)^2 + (1)^3 = 4 + 1 = 5$.
Therefore, the integral's value is $29 - 5 = 24$.
